Sprintex's G15 and G25 Jet Blowers offer ultra-high-speed, energy-efficient performance, reaching up to 100,000 RPM—three times faster than standard blowers. With Smart Pulse Aeration (SPA) Technology, they cut energy use by up to 70% and operate maintenance-free with intelligent controls for optimal durability and efficiency in industrial settings.
The single-stage compressor is engineered to achieve aerodynamic efficiency exceeding 80%.
With the highest power density available in the industry.
Our lightweight rotor design enhances the durability and reliability of the rotating assembly.
| Model | Max PressurekPa | Max Flowm3/min | Max Rotation Speedrpm | Max PowerkW | Dimensions mm |
Air Connection dia. mm |
Max Sound PressuredB(A) | Masskg |
|---|---|---|---|---|---|---|---|---|
| G25-G820 | 80 | 25 | 95,000 | 25 | 558x930x928 | 100 | 73 | 140 |
| G37-G835 | 80 | 36 | 95,000 | 37 | 558x930x928 | 100 | 73 | 160 |
| G55-G850 | 95 | 55 | 95,000 | 55 | 558x930x928 | 100 | 73 | 180 |
| Model | Max PressurekPa | Max Flowm3/min | Max Rotation Speedrpm | Max PowerkW | Dimensions mm |
Air Connection dia. mm |
Max Sound PressuredB(A) | Masskg |
|---|---|---|---|---|---|---|---|---|
| G15 4kW 30kPa | 40 | 7 | 80,000 | 4 | 503x359x341 | 75 | 72 | 11.8 |
| G15 7.5kW 30kPa | 40 | 13 | 80,000 | 7.5 | 601x265x374 | 75 | 74 | 14.8 |
| Model | Max PressurekPa | Max Flowm3/min | Max Rotation Speedrpm | Max PowerkW | Dimensions mm |
Air Connection dia. mm |
Max Sound PressuredB(A) | Masskg |
|---|---|---|---|---|---|---|---|---|
| G15 7.5kW 40kPa | 50 | 11.5 | 76,000 | 7.5 | 601x265x374 | 75 | 74 | 14.8 |
| G15 4kW 40kPa | 50 | 5 | 80,000 | 3.5 | 507x343x335 | 75 | 71 | 11.2 |
